Price range: $87,495.00 through $94,695.00
Signal Hound PCR4200 4-Channel Coherent Receiver THE PCR4200 4-CHANNEL COHERENT RECEIVER IS A HIGH-PERFORMANCE, 100 kHz – 20 GHz, 4-CHANNEL PHASE COHERENT RECEIVER, STREAMING I/Q DATA OVER A VITA 49 INTERFACE. This versatile multi-channel receiver features excellent dynamic range (110 dB), outstanding phase noise performance and extremely fast sweep speeds.... Read More
This versatile multi-channel receiver features excellent dynamic range (110 dB), outstanding phase noise performance and extremely fast sweep speeds. With built in GPS, a sub-octave preselector from 45 MHz to 20 GHz and capability to tune channels independently, the PCR4200 checks all the boxes for RF professionals working across a wide range of applications. This powerful product is equally effective on a bench top or in the field.
Unlocking multi-channel analysis brings signal identification to the next level. With capabilities to independently tune each channel or operate as phase coherent with 40 MHz of bandwidth, this high-performance piece of test equipment excels and wide-band, simultaneous monitoring uses.
High-performance, reliable and accurate – these are the assets users will find in the PCR4200. Months of research and development have yielded a superior product that delivers the cleanest signals and boasts RF specs . Customers always get more with Signal Hound products and the PCR4200 continues that trend. With features like a built-in vector signal generator that streamlines system alignment and calibration, as well as a customizable API for easy integration with 3rd-party software, this new product offers flexibility and user-friendly operation.
It is also important to note, the PCR4200 can be paired with an SM200 to utilize its incredibly fast sweep speeds – this allows all four channels of the PCR4200 to be tuned to specific frequencies, ensuring clear signal captures and the highest quality calibrated RF data.
The PCR4200 operates at a frequency range of 100 kHz to 20 GHz , includes SCPI automation capabilities, and interfaces with both Windows and Linux operating systems. With a standard operating temperature range of 32°F to 122°F (0°C to +50°C), the PCR4200 weighs 16.2 lbs. (7.34 kg) and measures 12” x 11.5” x 3” (274mm x 157mm x 38mm).
• Frequency Range 100 kHz to 20 GHz
• Streams 40 MHz Bandwidth per Channel over 10 GbE SFP+
• Built-in Sub-Octave Preselectors from 45 MHz to 20 GHz
• Built-in Vector Signal Generator
• Noise Figure: 9 dB Typical for X band
• Calibrated I/Q Data
• Ultra-Low Phase Noise: -136 dBc/Hz 10 kHz Offset from 1 GHz Center Frequency
• Internal GPS
• 110 dB Dynamic Range
• Each channel may be configured as:
• A Phase Coherent I/Q Channel
• An Independently Tuned I/Q Channel
• Up To 160 GHz/s Sweep Speed
• Up To 16 Phase Coherent Channels
Download: Signal Hound PCR4200 Data Sheet
| Weight | 7.5 kg |
|---|---|
| Dimensions | 28 × 16 × 4 cm |
| Temperature | Standard Temp. (0° to 50°C), Extended Temp. (-30°C to +60°C) |
